:CALibrate Commands 9

Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 255

:CALibrate:OUTPut

(see page 1138)

Command Syntax

:CALibrate:OUTPut <signal>

<signal> ::= {TRIGgers | MASK | WAVEgen}

The CALibrate:OUTPut command sets the signal that is available on the

rear panel TRIG OUT BNC:

• TRIGgers — pulse when a trigger event occurs.

• MASK — signal from mask test indicating a failure.

• WAVEgen — waveform generator sync output signal. This signal depends

on the :WGEN:FUNCtion setting:

Query Syntax

:CALibrate:OUTPut?

The :CALibrate:OUTPut query returns the current source of the TRIG OUT

BNC signal.

Return Format

<signal> ::= {TRIG | MASK | WAVE}

See Also • "Introduction to :CALibrate Commands" on page 251

• ":WGEN:FUNCtion" on page 1007

Waveform

Type

Sync Signal Characteristics

SINusoid,

SQUare,

RAMP,

PULSe, SINC,

EXPRise,

EXPFall,

GAUSsian

The Sync signal is a TTL positive pulse that occurs when the waveform rises

above zero volts (or the DC offset value).

DC, NOISe,

CARDiac

N/A
