Agilent Technologies InfiniiVision 3000 X-Series

634 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
27 :SBUS<n> Commands
:SBUS<n>:A429 Commands
NOTE
These commands are valid when the DSOX3AERO MIL-STD-1553 and ARINC 429 triggering
and serial decode option (Option AERO) has been licensed.
Table 100 :SBUS<n>:A429 Commands Summary
Command Query Options and Query Returns
:SBUS<n>:A429:AUToset
up (see page 636)
n/a n/a
:SBUS<n>:A429:BASE
<base> (see page 637)
:SBUS<n>:A429:BASE?
(see page 637)
<base> ::= {BINary | HEX}
n/a :SBUS<n>:A429:COUNt:E
RRor? (see page 638)
<error_count> ::= integer in NR1
format
:SBUS<n>:A429:COUNt:R
ESet (see page 639)
n/a n/a
n/a :SBUS<n>:A429:COUNt:W
ORD? (see page 640)
<word_count> ::= integer in NR1
format
:SBUS<n>:A429:FORMat
<format> (see
page 641)
:SBUS<n>:A429:FORMat?
(see page 641)
<format> ::= {LDSDi | LDSSm |
LDATa}
:SBUS<n>:A429:SIGNal
<signal> (see
page 642)
:SBUS<n>:A429:SIGNal?
(see page 642)
<signal> ::= {A | B |
DIFFerential}
:SBUS<n>:A429:SOURce
<source> (see
page 643)
:SBUS<n>:A429:SOURce?
(see page 643)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:A429:SPEed
<speed> (see
page 644)
:SBUS<n>:A429:SPEed?
(see page 644)
<speed> ::= {LOW | HIGH}
:SBUS<n>:A429:TRIGger
:LABel <value> (see
page 645)
:SBUS<n>:A429:TRIGger
:LABel? (see
page 645)
<value> ::= 8-bit integer in
decimal, <hex>, <octal>, or
<string> from 0-255 or "0xXX"
(don't care)
<hex> ::= #Hnn where n ::=
{0,..,9 | A,..,F}
<octal> ::= #Qnnn where n ::=
{0,..,7}
<string> ::= "0xnn" where n::=
{0,..,9 | A,..,F}
