:SBUS<n> Commands 27

Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 665

:SBUS<n>:CAN:TRIGger:PATTern:DATA

(see page 1138)

Command Syntax

:SBUS<n>:CAN:TRIGger:PATTern:DATA <string>

<string> ::= "nn...n" where n ::= {0 |1|X|$}

<string ::= "0xnn...n" where n ::= {0,..,9 | A,..,F | X | $}

The :SBUS<n>:CAN:TRIGger:PATTern:DATA command defines the CAN data

pattern resource according to the string parameter. This pattern, along

with the data length (set by the

:SBUS<n>:CAN:TRIGger:PATTern:DATA:LENGth command), control the data

pattern searched for in each CAN message.

If the string parameter starts with "0x", it is a hexadecimal string made up

of hexadecimal and X (don't care) characters; otherwise, it is a binary

string made up of 0, 1, and X (don't care) characters.

Query Syntax

:SBUS<n>:CAN:TRIGger:PATTern:DATA?

The :SBUS<n>:CAN:TRIGger:PATTern:DATA? query returns the current

settings of the specified CAN data pattern resource in the binary string

format.

Return Format

<string><NL> in nondecimal format

Errors • "- 241, Hardware missing" on page 1099

See Also • "Introduction to :TRIGger Commands" on page 877

• ":SBUS<n>:CAN:TRIGger:PATTern:DATA:LENGth" on page 666

• ":SBUS<n>:CAN:TRIGger:PATTern:ID" on page 667

NOTE

If more bits are sent for <string> than specified by the

:SBUS<n>:CAN:TRIGger:PATTern:DATA:LENGth command, the most significant bits will be

truncated. If the data length is changed after the <string> is programmed, the added or

deleted bits will be added to or deleted from the least significant bits.
