:MEASure Commands 20

Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 413

:MEASure:DEFine

(see page 1138)

Command Syntax

:MEASure:DEFine <meas_spec>

<meas_spec> ::= {DELay | THResholds}

The :MEASure:DEFine command sets up the definition for measurements

by specifying the delta time or threshold values. Changing these values

may affect the results of other measure commands. The table below

identifies which measurement results that can be affected by redefining

the DELay specification or the THResholds values. For example, changing

the THResholds definition from the default 10%, 50%, and 90% values may

change the returned measurement result.

:MEASure:DEFine

DELay Command

Syntax

:MEASure:DEFine DELay,<delay spec>

<edge_spec1> ::= [<slope>]<occurrence>

<edge_spec2> ::= [<slope>]<occurrence>

<slope> ::= {+ | -}

<occurrence> ::= integer

MEASure Command DELay THResholds

DUTYcycle x

DELay x x

FALLtime x

FREQuency x

NWIDth x

OVERshoot x

PERiod x

PHASe x

PREShoot x

PWIDth x

RISetime x

VAVerage x

VRMS x
