938 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide

31 :TRIGger Commands

:TRIGger:TRANsition Commands

The :TRIGger:TRANsition comamnds set the rise/fall time trigger options.

Table 134 :TRIGger:TRANsition Commands Summary

Command Query Options and Query Returns

:TRIGger:TRANsition:Q

UALifier <qualifier>

(see page 939)

:TRIGger:TRANsition:Q

UALifier? (see

page 939)

<qualifier> ::= {GREaterthan |

LESSthan}

:TRIGger:TRANsition:S

LOPe <slope> (see

page 940)

:TRIGger:TRANsition:S

LOPe? (see page 940)

<slope> ::= {NEGative | POSitive}

:TRIGger:TRANsition:S

OURce <source> (see

page 941)

:TRIGger:TRANsition:S

OURce? (see page 941)

<source> ::= CHANnel<n>

<n> ::= 1 to (# analog channels)

in NR1 format

:TRIGger:TRANsition:T

IME <time>[suffix]

(see page 942)

:TRIGger:TRANsition:T

IME? (see page 942)

<time> ::= floating-point number

in NR3 format

[suffix] ::= {s | ms | us | ns |

ps}
