Table 9 :DIGital<d> Commands Summary
Command Query Options and Query Returns
:DIGital<d>:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 291)
:DIGital<d>:DISPlay?
(see page 291)
<d> ::= 0 to (# digital channels
- 1) in NR1 format
{0 | 1}
:DIGital<d>:LABel
<string> (see
page 292)
:DIGital<d>:LABel?
(see page 292)
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<string> ::= any series of 10 or
less ASCII characters enclosed in
quotation marks
:DIGital<d>:POSition
<position> (see
page 293)
:DIGital<d>:POSition?
(see page 293)
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<position> ::= 0-7 if display
size = large, 0-15 if size =
medium, 0-31 if size = small
Returns -1 when there is no space
to display the digital waveform.
:DIGital<d>:SIZE
<value> (see
page 294)
:DIGital<d>:SIZE?
(see page 294)
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<value> ::= {SMALl | MEDium |
LARGe}
:DIGital<d>:THReshold
<value>[suffix] (see
page 295)
:DIGital<d>:THReshold
? (see page 295)
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<value> ::= {CMOS | ECL | TTL |
<user defined value>}
<user defined value> ::= value in
NR3 format from -8.00 to +8.00
[suffix] ::= {V | mV | uV}
Table 10 :DISPlay Commands Summary
Command Query Options and Query Returns
:DISPlay:ANNotation
{{0 | OFF} | {1 |
ON}} (see page 299)
:DISPlay:ANNotation?
(see page 299)
{0 | 1}
:DISPlay:ANNotation:B
ACKground <mode> (see
page 300)
:DISPlay:ANNotation:B
ACKground? (see
page 300)
<mode> ::= {OPAQue | INVerted |
TRANsparent}
:DISPlay:ANNotation:C
OLor <color> (see
page 301)
:DISPlay:ANNotation:C
OLor? (see page 301)
<color> ::= {CH1 | CH2 | CH3 |
CH4 | DIG | MATH | REF | MARKer |
WHITe | RED}
