16 :FUNCtion Commands
:FUNCtion[:FFT]:VTYPe
<units> (see
page 336)
:FUNCtion[:FFT]:VTYPe
? (see page 336)
<units> ::= {DECibel | VRMS}
:FUNCtion[:FFT]:WINDo
w <window> (see
page 337)
:FUNCtion[:FFT]:WINDo
w? (see page 337)
<window> ::= {RECTangular |
HANNing | FLATtop | BHARris}
:FUNCtion:FREQuency:H
IGHpass <3dB_freq>
(see page 338)
:FUNCtion:FREQuency:H
IGHpass? (see
page 338)
<3dB_freq> ::= 3dB cutoff
frequency value in NR3 format
:FUNCtion:FREQuency:L
OWPass <3dB_freq>
(see page 339)
:FUNCtion:FREQuency:L
OWPass? (see
page 339)
<3dB_freq> ::= 3dB cutoff
frequency value in NR3 format
:FUNCtion:GOFT:OPERat
ion <operation> (see
page 340)
:FUNCtion:GOFT:OPERat
ion? (see page 340)
<operation> ::= {ADD | SUBTract |
MULTiply}
:FUNCtion:GOFT:SOURce
1 <source> (see
page 341)
:FUNCtion:GOFT:SOURce
1? (see page 341)
<source> ::= CHANnel<n>
<n> ::= {1 | 2 | 3 | 4} for 4ch
models
<n> ::= {1 | 2} for 2ch models
:FUNCtion:GOFT:SOURce
2 <source> (see
page 342)
:FUNCtion:GOFT:SOURce
2? (see page 342)
<source> ::= CHANnel<n>
<n> ::= {1 | 2 | 3 | 4} for 4ch
models
<n> ::= {1 | 2} for 2ch models
:FUNCtion:INTegrate:I
OFFset <input_offset>
(see page 343)
:FUNCtion:INTegrate:I
OFFset? (see
page 343)
<input_offset> ::= DC offset
correction in NR3 format.
:FUNCtion:LINear:GAIN
<value> (see
page 344)
:FUNCtion:LINear:GAIN
? (see page 344)
<value> ::= 'A' in Ax + B, value
in NR3 format
:FUNCtion:LINear:OFFS
et <value> (see
page 345)
:FUNCtion:LINear:OFFS
et? (see page 345)
<value> ::= 'B' in Ax + B, value
in NR3 format
:FUNCtion:OFFSet
<offset> (see
page 346)
:FUNCtion:OFFSet?
(see page 346
)
<offset> ::= the value at center
screen in NR3 format.
The range of legal values is
+/-10 times the current
sensitivity of the selected
function.
Table 88 :FUNCtion Commands Summary (continued)
Command Query Options and Query Returns
