Agilent InfiniiVision 3000 X-Series Oscilloscopes
Programmer's Guide
16
:FUNCtion Commands
Control functions in the measurement/storage module. See "Introduction to
:FUNCtion Commands" on page 326.
Table 88 :FUNCtion Commands Summary
Command Query Options and Query Returns
:FUNCtion:BUS:CLOCk
<source> (see
page 328)
:FUNCtion:BUS:CLOCk?
(see page 328)
<source> ::= {CHANnel<n> |
DIGital<d>}
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:FUNCtion:BUS:SLOPe
<slope> (see
page 329)
:FUNCtion:BUS:SLOPe?
(see page 329)
<slope> ::= {NEGative | POSitive
| EITHer}
:FUNCtion:BUS:YINCrem
ent <value> (see
page 330)
:FUNCtion:BUS:YINCrem
ent? (see page 330)
<value> ::= value per bus code,
in NR3 format
:FUNCtion:BUS:YORigin
<value> (see
page 331)
:FUNCtion:BUS:YORigin
? (see page 331)
<value> ::= value at bus code =
0, in NR3 format
:FUNCtion:BUS:YUNits
<units> (see
page 332)
:FUNCtion:BUS:YUNits?
(see page 332)
<units> ::= {VOLT | AMPere |
NONE}
:FUNCtion:DISPlay {{0
| OFF} | {1 | ON}}
(see page 333)
:FUNCtion:DISPlay?
(see page 333)
{0 | 1}
:FUNCtion[:FFT]:CENTe
r <frequency> (see
page 334)
:FUNCtion[:FFT]:CENTe
r? (see page 334)
<frequency> ::= the current
center frequency in NR3 format.
The range of legal values is from
0 Hz to 25 GHz.
:FUNCtion[:FFT]:SPAN
<span> (see page 335)
:FUNCtion[:FFT]:SPAN?
(see page 335)
<span> ::= the current frequency
span in NR3 format.
Legal values are 1 Hz to 100 GHz.
