Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

82 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
n/a :TER? (see page 224) {0 | 1}
:VIEW <source> (see
page 225)
n/a <source> ::= {CHANnel<n> |
FUNCtion | MATH | SBUS{1 | 2} |
WMEMory<r>} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | POD{1 | 2} | BUS{1 |
2} | FUNCtion | MATH | SBUS{1 |
2} | WMEMory<r>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
Table 3 Root (:) Commands Summary (continued)
Command Query Options and Query Returns
Table 4 :ACQuire Commands Summary
Command Query Options and Query Returns
:ACQuire:COMPlete
<complete> (see
page 229)
:ACQuire:COMPlete?
(see page 229)
<complete> ::= 100; an integer in
NR1 format
:ACQuire:COUNt
<count> (see
page 230)
:ACQuire:COUNt? (see
page 230)
<count> ::= an integer from 2 to
65536 in NR1 format
:ACQuire:MODE <mode>
(see page 231)
:ACQuire:MODE? (see
page 231)
<mode> ::= {RTIMe | SEGMented}
n/a :ACQuire:POINts? (see
page 232)
<# points> ::= an integer in NR1
format
:ACQuire:SEGMented:AN
ALyze (see page 233)
n/a n/a (with Option SGM)
:ACQuire:SEGMented:CO
UNt <count> (see
page 234)
:ACQuire:SEGMented:CO
UNt? (see page 234)
<count> ::= an integer from 2 to
1000 in NR1 format (with Option
SGM)
:ACQuire:SEGMented:IN
Dex <index> (see
page 235)
:ACQuire:SEGMented:IN
Dex? (see page 235)
<index> ::= an integer from 1 to
1000 in NR1 format (with Option
SGM)
n/a :ACQuire:SRATe? (see
page 238)
<sample_rate> ::= sample rate
(samples/s) in NR3 format
:ACQuire:TYPE <type>
(see page 239)
:ACQuire:TYPE? (see
page 239)
<type> ::= {NORMal | AVERage |
HRESolution | PEAK}
