86 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:CHANnel<n>:RANGe
<range>[suffix] (see
page 277)
:CHANnel<n>:RANGe?
(see page 277)
<range> ::= Vertical full-scale
range value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:SCALe
<scale>[suffix] (see
page 278)
:CHANnel<n>:SCALe?
(see page 278)
<scale> ::= Vertical units per
division value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:UNITs
<units> (see
page 279)
:CHANnel<n>:UNITs?
(see page 279)
<units> ::= {VOLT | AMPere}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:VERNier
{{0 | OFF} | {1 |
ON}} (see page 280)
:CHANnel<n>:VERNier?
(see page 280)
{0 | 1}
<n> ::= 1 to (# analog channels)
in NR1 format
Table 7 :CHANnel<n> Commands Summary (continued)
Command Query Options and Query Returns
Table 8 :DEMO Commands Summary
Command Query Options and Query Returns
:DEMO:FUNCtion
<signal> (see
page 282)
:DEMO:FUNCtion? (see
page 284)
<signal> ::= {SINusoid | NOISy |
PHASe | RINGing | SINGle | AM |
CLK | GLITch | BURSt | MSO | RUNT
| TRANsition | RFBurst | SHOLd |
LFSine | FMBurst | ETE | CAN |
LIN | UART | I2C | SPI | I2S |
CANLin | ARINc | FLEXray | MIL |
MIL2}
:DEMO:FUNCtion:PHASe:
PHASe <angle> (see
page 286)
:DEMO:FUNCtion:PHASe:
PHASe? (see page 286)
<angle> ::= angle in degrees from
0 to 360 in NR3 format
:DEMO:OUTPut {{0 |
OFF} | {1 | ON}} (see
page 287)
:DEMO:OUTPut? (see
page 287)
{0 | 1}
