Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 85
:CHANnel<n>:IMPedance
<impedance> (see
page 267)
:CHANnel<n>:IMPedance
? (see page 267)
<impedance> ::= {ONEMeg | FIFTy}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:INVert
{{0 | OFF} | {1 |
ON}} (see page 268)
:CHANnel<n>:INVert?
(see page 268)
{0 | 1}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:LABel
<string> (see
page 269)
:CHANnel<n>:LABel?
(see page 269)
<string> ::= any series of 10 or
less ASCII characters enclosed in
quotation marks
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:OFFSet
<offset>[suffix] (see
page 270)
:CHANnel<n>:OFFSet?
(see page 270)
<offset> ::= Vertical offset
value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1-2 or 1-4; in NR1 format
:CHANnel<n>:PROBe
<attenuation> (see
page 271)
:CHANnel<n>:PROBe?
(see page 271)
<attenuation> ::= Probe
attenuation ratio in NR3 format
<n> ::= 1-2 or 1-4r in NR1 format
:CHANnel<n>:PROBe:HEA
D[:TYPE] <head_param>
(see page 272)
:CHANnel<n>:PROBe:HEA
D[:TYPE]? (see
page 272)
<head_param> ::= {SEND0 | SEND6 |
SEND12 | SEND20 | DIFF0 | DIFF6 |
DIFF12 | DIFF20 | NONE}
<n> ::= 1 to (# analog channels)
in NR1 format
n/a :CHANnel<n>:PROBe:ID?
(see page 273)
<probe id> ::= unquoted ASCII
string up to 11 characters
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:PROBe:SKE
W <skew_value> (see
page 274)
:CHANnel<n>:PROBe:SKE
W? (see page 274)
<skew_value> ::= -100 ns to +100
ns in NR3 format
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:PROBe:STY
Pe <signal type> (see
page 275)
:CHANnel<n>:PROBe:STY
Pe? (see page 275)
<signal type> ::= {DIFFerential |
SINGle}
<n> ::= 1 to (# analog channels)
in NR1 format
:CHANnel<n>:PROTectio
n (see page 276
)
:CHANnel<n>:PROTectio
n? (see page 276)
{NORM | TRIP}
<n> ::= 1 to (# analog channels)
in NR1 format
Table 7 :CHANnel<n> Commands Summary (continued)
Command Query Options and Query Returns
