Agilent Technologies InfiniiVision 3000 X-Series

90 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:FUNCtion:BUS:YUNits
<units> (see
page 332)
:FUNCtion:BUS:YUNits?
(see page 332)
<units> ::= {VOLT | AMPere |
NONE}
:FUNCtion:DISPlay {{0
| OFF} | {1 | ON}}
(see page 333)
:FUNCtion:DISPlay?
(see page 333)
{0 | 1}
:FUNCtion[:FFT]:CENTe
r <frequency> (see
page 334)
:FUNCtion[:FFT]:CENTe
r? (see page 334)
<frequency> ::= the current
center frequency in NR3 format.
The range of legal values is from
0 Hz to 25 GHz.
:FUNCtion[:FFT]:SPAN
<span> (see page 335)
:FUNCtion[:FFT]:SPAN?
(see page 335)
<span> ::= the current frequency
span in NR3 format.
Legal values are 1 Hz to 100 GHz.
:FUNCtion[:FFT]:VTYPe
<units> (see
page 336)
:FUNCtion[:FFT]:VTYPe
? (see page 336)
<units> ::= {DECibel | VRMS}
:FUNCtion[:FFT]:WINDo
w <window> (see
page 337)
:FUNCtion[:FFT]:WINDo
w? (see page 337)
<window> ::= {RECTangular |
HANNing | FLATtop | BHARris}
:FUNCtion:FREQuency:H
IGHpass <3dB_freq>
(see page 338)
:FUNCtion:FREQuency:H
IGHpass? (see
page 338)
<3dB_freq> ::= 3dB cutoff
frequency value in NR3 format
:FUNCtion:FREQuency:L
OWPass <3dB_freq>
(see page 339)
:FUNCtion:FREQuency:L
OWPass? (see
page 339)
<3dB_freq> ::= 3dB cutoff
frequency value in NR3 format
:FUNCtion:GOFT:OPERat
ion <operation> (see
page 340)
:FUNCtion:GOFT:OPERat
ion? (see page 340)
<operation> ::= {ADD | SUBTract |
MULTiply}
:FUNCtion:GOFT:SOURce
1 <source> (see
page 341)
:FUNCtion:GOFT:SOURce
1? (see page 341)
<source> ::= CHANnel<n>
<n> ::= {1 | 2 | 3 | 4} for 4ch
models
<n> ::= {1 | 2} for 2ch models
:FUNCtion:GOFT:SOURce
2 <source> (see
page 342)
:FUNCtion:GOFT:SOURce
2? (see page 342)
<source> ::= CHANnel<n>
<n> ::= {1 | 2 | 3 | 4} for 4ch
models
<n> ::= {1 | 2} for 2ch models
:FUNCtion:INTegrate:I
OFFset <input_offset>
(see page 343)
:FUNCtion:INTegrate:I
OFFset? (see
page 343)
<input_offset> ::= DC offset
correction in NR3 format.
Table 13 :FUNCtion Commands Summary (continued)
Command Query Options and Query Returns
