Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 91
:FUNCtion:LINear:GAIN
<value> (see
page 344)
:FUNCtion:LINear:GAIN
? (see page 344)
<value> ::= 'A' in Ax + B, value
in NR3 format
:FUNCtion:LINear:OFFS
et <value> (see
page 345)
:FUNCtion:LINear:OFFS
et? (see page 345)
<value> ::= 'B' in Ax + B, value
in NR3 format
:FUNCtion:OFFSet
<offset> (see
page 346)
:FUNCtion:OFFSet?
(see page 346)
<offset> ::= the value at center
screen in NR3 format.
The range of legal values is
+/-10 times the current
sensitivity of the selected
function.
:FUNCtion:OPERation
<operation> (see
page 347)
:FUNCtion:OPERation?
(see page 348)
<operation> ::= {ADD | SUBTract |
MULTiply | INTegrate | DIFF | FFT
| SQRT | MAGNify | ABSolute |
SQUare | LN | LOG | EXP | TEN |
LOWPass | HIGHpass | DIVide |
LINear | TRENd | BTIMing |
BSTate}
:FUNCtion:RANGe
<range> (see
page 349)
:FUNCtion:RANGe? (see
page 349)
<range> ::= the full-scale
vertical axis value in NR3
format.
The range for ADD, SUBT, MULT is
8E-6 to 800E+3. The range for the
INTegrate function is 8E-9 to
400E+3.
The range for the DIFF function
is 80E-3 to 8.0E12 (depends on
current sweep speed).
The range for the FFT function is
8 to 800 dBV.
:FUNCtion:REFerence
<level> (see
page 350)
:FUNCtion:REFerence?
(see page 350)
<level> ::= the value at center
screen in NR3 format.
The range of legal values is
+/-10 times the current
sensitivity of the selected
function.
:FUNCtion:SCALe
<scale
value>[<suffix>] (see
page 351)
:FUNCtion:SCALe? (see
page 351)
<scale value> ::= integer in NR1
format
<suffix> ::= {V | dB}
Table 13 :FUNCtion Commands Summary (continued)
Command Query Options and Query Returns
