11 :DEMO Commands
Query Syntax :DEMO:FUNCtion?
The :DEMO:FUNCtion? query returns the currently selected demo signal
type.
Return Format
<signal><NL>
SPI Off
Signals are internally routed to digital
channels D6 through D9:
• D9 — MOSI, TTL level, with MSB
out 1st (internally routed to digital
input).
• D8 — MISO, TTL level, with MSB
out 1st (internally routed to digital
input).
• D7 — CLK, TTL level (internally
routed to digital input).
• D6 — ~CS, low-enable, TTL level
(internally routed to digital input).
Off
I2S Off
Signals are internally routed to digital
channels D7 through D9:
• D9 — SDATA, TTL level, with
"standard" alignment (internally
routed to digital input).
• D8 — SCLK, TTL level, (internally
routed to digital input).
• D7 — WS, TTL level, low for left
channel, high for right channel
(internally routed to digital input)
Off
CANLin CAN_L, 250 kbps dominant-low,
~2.8 Vpp, ~1.4 V offset
LIN, 19.2 kbps, ~2.8 Vpp, ~1.4 V
offset
ARINc ARINC 429, 100 kbps, ~5 Vpp, ~0 V
offset.
Off
FLEXray FlexRay @ 10 Mbps, ~2.8 Vpp, ~0 V
offset
Off
MIL MIL-STD-1553 RT to RT transfer,
received ~1.3 Vpp, transmitted
~4.8 Vpp, 0 V offset
Off
MIL2 MIL-STD-1553 RT to RT transfer,
received ~1.3 Vpp, transmitted
~4.8 Vpp, 0 V offset
MIL-STD-1553 RT to BC transfer,
received ~1.3 Vpp, transmitted
~4.8 Vpp, 0 V offset
Demo Signal
Function
Demo 1 Terminal Demo 2 Terminal
