Agilent InfiniiVision 3000 X-Series Oscilloscopes
Programmer's Guide
19
:MARKer Commands
Set and query the settings of X-axis markers (X1 and X2 cursors) and the
Y- axis markers (Y1 and Y2 cursors). See "Introduction to :MARKer
Commands" on page 380.
Table 91 :MARKer Commands Summary
Command Query Options and Query Returns
:MARKer:MODE <mode>
(see page 381)
:MARKer:MODE? (see
page 381)
<mode> ::= {OFF | MEASurement |
MANual | WAVeform}
:MARKer:X1Position
<position>[suffix]
(see page 382)
:MARKer:X1Position?
(see page 382)
<position> ::= X1 cursor position
value in NR3 format
[suffix] ::= {s | ms | us | ns |
ps | Hz | kHz | MHz}
<return_value> ::= X1 cursor
position value in NR3 format
:MARKer:X1Y1source
<source> (see
page 383)
:MARKer:X1Y1source?
(see page 383)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= <source>
:MARKer:X2Position
<position>[suffix]
(see page 384)
:MARKer:X2Position?
(see page 384)
<position> ::= X2 cursor position
value in NR3 format
[suffix] ::= {s | ms | us | ns |
ps | Hz | kHz | MHz}
<return_value> ::= X2 cursor
position value in NR3 format
:MARKer:X2Y2source
<source> (see
page 385)
:MARKer:X2Y2source?
(see page 385)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= <source>
n/a :MARKer:XDELta? (see
page 386)
<return_value> ::= X cursors
delta value in NR3 format
