Agilent InfiniiVision 3000 X-Series Oscilloscopes
Programmer's Guide
21
:MEASure Power Commands
These :MEASure commands are available when the DSOX3PWR power
measurements and analysis application is licensed and enabled.
Table 93 :MEASure Power Commands Summary
Command Query Options and Query Returns
:MEASure:ANGLe
[<source1>][,<source2
>] (see page 472)
:MEASure:ANGLe?
[<source1>][,<source2
>] (see page 472)
<source1>, <source2> ::=
{CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= the power
phase angle in degrees in NR3
format
:MEASure:APParent
[<source1>][,<source2
>] (see page 473)
:MEASure:APParent?
[<source1>][,<source2
>] (see page 473)
<source1>, <source2> ::=
{CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= the apparent
power value in NR3 format
:MEASure:CPLoss
[<source1>][,<source2
>] (see page 474)
:MEASure:CPLoss?
[<source1>][,<source2
>] (see page 474)
<source1>, <source2>
<source1> ::= {FUNCtion | MATH}
<source2> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= the switching
loss per cycle watts value in NR3
format
:MEASure:CRESt
[<source>] (see
page 475)
:MEASure:CRESt?
[<source>] (see
page 475)
<source> ::= {CHANnel<n>|
FUNCtion | MATH}
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= the crest
factor value in NR3 format
:MEASure:EFFiciency
(see page 476)
:MEASure:EFFiciency?
(see page 476)
<return_value> ::= percent value
in NR3 format
