:SAVE Commands 26

Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 607

Introduction to

:SAVE Commands

The :SAVE subsystem provides commands to save oscilloscope setups,

screen images, and data.

:SAV is an acceptable short form for :SAVE.

Reporting the Setup

Use :SAVE? to query setup information for the SAVE subsystem.

Return Format

The following is a sample response from the :SAVE? query. In this case,

the query was issued following the *RST command.

:SAVE:FIL "";:SAVE:IMAG:AREA GRAT;FACT 0;FORM TIFF;INKS 0;PAL

MON;:SAVE:PWD "C:/setups/";:SAVE:WAV:FORM NONE;LENG 1000;SEGM CURR

:SAVE:WMEMory:SOURce

<source> (see

page 626)

:SAVE:WMEMory:SOURce?

(see page 626)

<source> ::= {CHANnel<n> |

FUNCtion | MATH | WMEMory<r>}

<n> ::= 1 to (# analog channels)

in NR1 format

<r> ::= 1-2 in NR1 format

NOTE: Only ADD or SUBtract math

operations can be saved as

reference waveforms.

<return_value> ::= <source>

:SAVE:WMEMory[:STARt]

[<file_name>] (see

page 627)

n/a <file_name> ::= quoted ASCII

string

If extension included in file

name, it must be ".h5".

Table 98 :SAVE Commands Summary (continued)

Command Query Options and Query Returns
