Agilent InfiniiVision 3000 X-Series Oscilloscopes
Programmer's Guide
33
:WGEN Commands
When the built- in waveform generator is licensed (Option WGN), you can
use it to output sine, square, ramp, pulse, DC, noise, sine cardinal,
exponential rise, exponential fall, cardiac, and gaussian pulse waveforms.
The :WGEN commands are used to select the waveform function and
parameters. See "Introduction to :WGEN Commands" on page 998.
Table 139 :WGEN Commands Summary
Command Query Options and Query Returns
:WGEN:ARBitrary:BYTeo
rder <order> (see
page 999)
:WGEN:ARBitrary:BYTeo
rder? (see page 999)
<order> ::= {MSBFirst | LSBFirst}
:WGEN:ARBitrary:DATA
{<binary> | <value>,
<value> ...} (see
page 1000)
n/a <binary> ::= single-presision
floating point values between
-1.0 to +1.0 in IEEE 488.2 binary
block format
<value> ::= floating point values
between -1.0 to +1.0 in
comma-separated format
n/a :WGEN:ARBitrary:DATA:
ATTRibute:POINts?
(see page 1001)
<points> ::= number of points in
NR1 format
:WGEN:ARBitrary:DATA:
CLEar (see page 1002)
n/a n/a
:WGEN:ARBitrary:DATA:
DAC {<binary> |
<value>, <value> ...}
(see page 1003)
n/a <binary> ::= decimal 16-bit
integer values between -512 to
+511 in IEEE 488.2 binary block
format
<value> ::= decimal integer
values between -512 to +511 in
comma-separated NR1 format
:WGEN:ARBitrary:INTer
polate {{0 | OFF} |
{1 | ON}} (see
page 1004)
:WGEN:ARBitrary:INTer
polate? (see
page 1004)
{0 | 1}
