EPSON AcuLaser CX11/CX11F Revision B
DISASSEMBLY AND ASSEMBLY Printer 343
REINSTALLATION
1. Match the hole on OIL DAMPER with the boss on DAMPER BRACKET, and
attach OIL DAMPER to DAMPER BRACKET.
2. Match the hole on DAMPER BRACKET with the boss on MSI ASSY, and attach
OIL DAMPER together with DAMPER BRACKET.
3. Fasten DAMPER BRACKET to MSI ASSY with the 2 screws (silver, with flange,
tapping, 8 mm).
4. Attach GEAR PICK UP to SHAFT ASSY MSI, and fasten the hook on GEAR
PICK UP to the groove on SHAFT ASSY MSI.
5. Attach MSI ASSY. (p329)
6. Attach FRAME ASSY-PH. (p352)
7. Attach COVER FRONT L and COVER FRONT ASSY U. (p318)
8. Attach COVER MSI. (p317)
9. Attach COVER ASSY LH. (p321)
10. Attach COVER ASSY RH. (p326)
C A U T I O N
When performing the following work, pay attention to the
attachment direction of OIL DAMPER.
