EPSON AcuLaser CX11/CX11F Revision B
DISASSEMBLY AND ASSEMBLY Printer 345
REINSTALLATION
1. Match the hole on SOLENOID PICK UP with the boss on MSI ASSY, and attach
SOLENOID PICK UP.
2. Fasten SOLENOID PICK UP to MSI ASSY with the screw (silver, tapping,
8mm).
3. Connect connector (P/J605) to SOLENOID PICK UP, and route the harness in the
notch and groove on MSI ASSY.
4. Attach GEAR PICK UP to SHAFT ASSY MSI while pulling the lever on
SOLENOID PICK UP, and fasten the hook on GEAR PICK UP to the groove on
SHAFT ASSY MSI.
5. Attach MSI ASSY. (p329)
6. Attach FRAME ASSY-PH. (p352)
7. Attach COVER FRONT L and COVER FRONT ASSY U. (p318)
8. Attach COVER MSI. (p317)
9. Attach COVER ASSY LH. (p321)
10. Attach COVER ASSY RH. (p326)
