EPSON AcuLaser CX11/CX11F Revision B
DISASSEMBLY AND ASSEMBLY Printer 377
REINSTALLATION
1. Attach BEARING to the left-side bearing on the main unit.
2. Attach BEARING to the right-side bearing on CAM ASSY-2ND.
3. Insert the right-side bearing on CAM ASSY-2ND into the right-side bearing on
the main unit, slide CAM ASSY-2ND to the left, and attach CAM ASSY-2ND
together with BEARING.
4. Insert the right-side BEARING on CAM ASSY-2ND into the right-side bearing
on the main unit, and fasten with an E-ring.
5. Remove SENSOR 2BTR RETRACT. (p382)
6. Attach PLATE BIAS-2ND ASSY. (p384)
7. Attach 2ND BTR ASSY. (p374)
8. Attach CHUTE ASSY-FSR and COVER ASSY-RR 2ND. (p366)
9. Attach COVER ASSY RH. (p326)
C H E C K
P O I N T
When performing the following work, work can be performed more
easily by pressing FRAME ASSY-2ND in the direction of the arrow,
and releasing FRAME ASSY-2ND from the cam on CAM ASSY-
2ND. (Refer to Figure 4-65)
C A U T I O N
Make sure that the cam on CAM ASSY-2ND is matched with the
cam receptacle on FRAME ASSY-2ND. (Refer to Figure 4-65)
