Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
APPENDIX Fax Unit System 655
COM_V29_EPTONE 310 060
---
0D0
Enables or disables superimposing V.29 EP-tone
Set whether superimpose or not superimpose EP-tone to V.29 tones
based on the ITU-T G3 standard.
0 = Disable
1 = Enable
Disable
(0)
---
COM_BYTE_DIS_DTC 310 061
---
0D1 Number of bytes for transmitting FIF of DIS/DTC
DTC: Transmit command corresponds to DIS.
0 = 4 bytes system
1 = 5 bytes system
2 = 6 bytes system
3 = 7 bytes system
4 = 8 bytes system
5 = 9 bytes system
6 = 10 bytes system
7 = 11 bytes system
8 = 12 bytes system
9 = 13 bytes system
10 = 14 bytes system (maximum capacity)
10bytes
(6)
---
COM_CTC_NUM 310 062
---
0D2 Number of transmitting CTC 0=000 to 7=111 5
---
COM_T5_TIME 310 063
---
0D3 ECM T5 timer
Timer for RNR signal sent from the receiving machine when the
receiving machine cannot continue to receive a fax due to
insufficient memory or any other troubles.
0 to 255 sec (1 step = 1 sec) 65 seconds
(65)
---
COM_EQM_48 310 064
---
0D4 EQU comparison value at 4800 bps 0 to 0x7F FTT transmitting criterion 0x3A
---
COM_EQM_72 310 065
---
0D5
EQU comparison value at 7200 bps 0 to 0x7F FTT transmitting criterion 0x32 ---
COM_EQM_96 310 066
---
0D6
EQU comparison value at 9600 bps 0 to 0x7F FTT transmitting criterion 0x3A ---
COM_EQM_120 310 067
---
0D7 EQU comparison value at 12000 bps 0 to 0x7F FTT transmitting criterion 0x4F
---
COM_EQM_144 310 068
---
0D8 EQU comparison value at 14400 bps 0 to 0x7F FTT transmitting criterion 0x3F
---
COM_EQM_TCM72 310 069
---
0D9 EQU comparison value at TCM 7200 bps 0 to 0x7F FTT transmitting criterion 0x48
---
COM_EQM_TCM96 310 070
---
0DA EQU comparison value at TCM 9600 bps 0 to 0x7F FTT transmitting criterion 0x4E
---
COM_TX_CODE 310 071
---
0DB Encoding method for transmission
Changes the method according to the receiving machine
performance.
0 = MH
1 = MR
2 = MMR
3 = JBIG(Not used)
MMR
(2)
---
COM_RX_CODE 310 072
---
0DC Encoding method for reception 0 = MH
1 = MR
2 = MMR
3 = JBIG(Not used)
MMR
(2)
---
COM_V34_GAIN_CHG 310 073
---
0DD Gain switching mode when detecting V.34 tones 0 = Not switch the gain
1 = Switches the gain
Switches
(1)
---
Table 7-19. List of System Parameter (Communication Control)
Label
Maintenanc
e Code
User
Access
Internal
Address
Description Setting Value Default
Remark
s
Main Sub
