Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
APPENDIX Fax Unit System 654
COM_DIS_NEGLECT_NUM 310 051
---
0C7
Number of ignoring DIS 0 to 255 times (1 step = 1 time)
0 time
(0)
COM_TSI_CIG_SEND 310 052
---
0C8
Transmitting TSI and CIG
TSI: Signal that notifies ID of the sending machine as a response to
CSI signal sent from the receiving machine.
CIG :Signal that indicates identification information on the sending
machine.
0 = AUTO
1 = forced transmit
2 = not transmit
AUTO
(0)
---
COM_CSI_SEND 310 053
---
0C9
Transmitting CSI
CSI :Signal that notifies the sending machine of ID code of the
receiving machine.
0 = Transmit
1 = off
transmit
(0)
---
COM_FTT_FALLBACK 310 054
---
0CA
FTT number for judging fallback
Number of FTT until the product falls back at 14400/12000/9600/
7200/4800/2400 bps.
“Fallback” means an operation to find out an acceptable
communication speed for the receiving machine by reestablishing
the communication at lower speed when a training check signal at
certain transmitting speed is rejected by the receiving machine.
0 = All 2 FTT Fall Back
2 = All 1 FTT Fall Back
All 2 FTT
(0)
---
COM_TCF_CHECK 310 055
---
0CB
TCF signal judging time
TCF: Training check signal consists of “0” signal for about 1.5 seconds.
0 = 1.2 seconds
1 = 1.0 second
1.2 seconds
(0)
---
COM_TX_CABLE_EQU 310 056
---
0CC
Transmitting cable equalizer 0 = 0db (equivalent to 0 Km)
1 = 4db (equivalent to 1.8 Km)
2 = 8db (equivalent to 3.6 Km)
3 = 12db (equivalent to 7.2 Km)
8db
(2)
---
COM_RX_CABLE_EQU 310 057
---
0CD
Receiving cable equalizer 0 = 0db (equivalent to 0 Km)
1 = 4db (equivalent to 1.8 Km)
2 = 8db (equivalent to 3.6 Km)
3 = 12db (equivalent to 7.2 Km)
8db
(2)
---
COM_TAP_HOLD 310 058
---
0CE
Enables or disables tap hold 0 = Disable
1 = Enable (equalizer freeze)
Enable
(1)
---
COM_RX_RESO 310 059
---
0CF
Specify resolution for received fax
(for evaluation)
0 x 00 = Default
0x01 = (Not used)
0x02 = (Not used)
0x04 = R8x15.4l/mmÅAR8x7.7l/mmÅA
R8x3.85l/mm
0x08 = (Not used)
0x10 = (Not used)
0x20 = R8x7.7l/mmÅAR8x3.85l/mm
0x40 = (Not used)
0x80 = R8x3.85l/mm
(0x00)
---
Table 7-19. List of System Parameter (Communication Control)
Label
Maintenanc
e Code
User
Access
Internal
Address
Description Setting Value Default
Remark
s
Main Sub
