Epson AcuLaser CX11 Service Manual

EPSON AcuLaser CX11/CX11F Revision B
APPENDIX Fax Unit System 653
COM_T4_TIME_AUTO 310 041
---
0BD
T4 timer when communicating automatically
T4 timer for automatic transmitting and receiving
0 to 25.5 sec (1 step = 100 ms) 3 seconds
(30)
---
COM_T4_TIME_MANU 310 042
---
0BE
T4 timer when communicating manually
T4 timer for manual transmitting and receiving
0 to 25.5 sec (1 step = 100 ms) 4.5 seconds
(45)
---
COM_SOUNDLESS_TIME 310 043
---
0BF
T.30 noiseless timer
Timer for noiseless time recommended by T.30.
0 to 255 ms (1 step = 1 ms)
75 ms
(75)
---
COM_FSK_CHK_TIME 310 044
---
0C0
FSK receiving judge timer
When the product is waiting for incoming data in high speed
receiving mode, it judges that the incoming fax is FSK within the
set time interval.
0 to 255 ms (1 step = 1 ms)
200 ms
(200)
---
COM_PIX_DELAY 310 045
---
0C1
Time interval before starting to transmit image data in G3 mode 0 to 2550 ms (1 step = 10 ms)
500 ms
(50)
---
COM_DROP_OUT_TIME 310 046
---
0C2
Drop-out judging timer when receiving image data
Time interval from carrier down in the middle of receiving image
data to when judging it as drop-out.
0 to 2550 ms (1 step = 10 ms)
1000 ms
(100)
---
COM_DIS_RESEND_TIME 310 047
---
0C3
NSF, DIS resend timer
NSF: Signal to indicate that the receiving fax machine supports
functions other than those given in ITU-T G3 standard.
DIS: Signal to notify the sender that the receiving fax machine
features meet the ITU-T G3 standard.
0 = 3 seconds
1 = 3.45 seconds
2 = 2.55 seconds
3 = 4.5 seconds
3 seconds
(0)
---
COM_TX_SPEED 310 048
---
0C4
Transmitting speed performance
Enabled when communicating at V.17 or lower.
0 = Fallback by best performance of the
receiving machine
1 =V.27 ter fallback mode (2400 bps) only
2 =V.27 ter fallback mode (2400, 4800 bps)
only
3 =V.29 (7200, 9600 bps) only
4 = V.33(TC12000bps,TC14400bps) only
5 = V.17(TC7200bps, TC9600bps,
TC12000bps, TC14400bps) only
(0)
---
COM_RX_SPEED 310 049
---
0C5
Receiving speed performance
Reception mode that receives a fax declaring DIS, NSF (DTC,
NSC).
Enabled when communicating at V.17 or lower.
0 =V.27ter, V.29, V.33 and V.17
1 =V.27ter fallback mode (2400 bps)
2 = V.27ter(2400bps,4800bps)
3 = V.29(7200bps,9600bps)
4 =V.27ter and V.29
5 =V.27ter, V.29 and V33
(0)
---
COM_MODEM_MODE 310 050
---
0C6
Modem mode 0 = Auto (unique mode enabled)
1 = ITU-T G3 (unique mode disabled)
ITU-T G3
(1)
Fixed to 1
Table 7-19. List of System Parameter (Communication Control)
Label
Maintenanc
e Code
User
Access
Internal
Address
Description Setting Value Default
Remark
s
Main Sub
