Huawei Quidway S3900 Series Command Manual

Command Manual – Link Aggregation
Quidway S3900 Series Ethernet Switches-Release 1510
Chapter 1 Link Aggregation Configuration
Commands
Huawei Technologies Proprietary
1-3
Description
Use the display link-aggregation summary command to display summary
information of all aggregation groups, including device ID of the local end, aggregation
group ID, aggregation group type, device ID of the remote end, number of the selected
ports, number of the unselected ports, load sharing type and master port number.
Example
# Display summary information of all aggregation groups.
<Quidway> display link-aggregation summary
Aggregation Group Type:D -- Dynamic, S -- Static , M -- Manual
Loadsharing Type: Shar -- Loadsharing, NonS -- Non-Loadsharing
Actor ID: 0x8000, 00e0-fc00-5104
AL AL Partner ID Select Unselect Share Master
ID Type Ports Ports Type Port
--------------------------------------------------------------------------
1 S 0x8000,0000-0000-0000 0 1 NonS Ethernet1/0/2
2 M none 0 1 NonS Ethernet1/0/3
Table 1-2 Description on the fields of the display link-aggregation summary
command
Field Description
Aggregation
Group Type
Aggregation group type
Actor ID Local device ID
AL ID Aggregation group ID
AL Type Aggregation group type: D (dynamic), S (static), or M (manual)
Partner ID
ID of the remote device, including the system priority and
system MAC address of the remote device (in the dynamic or
static aggregation group, if the LACP protocol is disabled on
the remote port of the logical master port, the partner ID
displays 0x8000,0000-0000-0000 )
Select Ports Number of the selected ports
Unselect Ports Number of the unselected ports
Share Type
Load sharing type: Shar (load-sharing), or NonS
(non-load-sharing)
