Huawei Quidway S3900 Series Command Manual

Command Manual – Mirroring
Quidway S3900 Series Ethernet Switches-Release 1510 Chapter 1 Mirroring Commands
Huawei Technologies Proprietary
1-3
Example
# Display the parameter settings of traffic mirroring on Gigabitethernet1/1/1.
<Quidway> display qos-interface GigabitEthernet 1/1/1 mirrored-to
GigabitEthernet1/1/1: mirrored-to
Inbound:
Matches: Acl 2000 rule 0 running
Mirrored to: monitor interface
1.1.3 mirrored-to
Syntax
mirrored-to { inbound | outbound } acl-rule { monitor-interface | cpu }
undo mirrored-to { inbound | outbound } acl-rule
View
Ethernet port view
Parameter
inbound: Mirrors packets received on the port.
outbound: Mirrors packets sent on the port.
acl-rule: Applied ACL rules, which can be the combination of different types of ACL
rules.
Table 1-1 describes the ACL combinations.
Table 1-1 Combined application of ACLs
Combination mode Form of acl-rule
Apply all rules in an IP type ACL (either a basic
or an advanced ACL) separately
ip-group acl-number
Apply one rule in an IP type ACL separately
ip-group acl-number rule rule-id
Apply all rules in a Layer 2 ACL separately
link-group acl-number
Apply one rule in a Layer 2 ACL separately
link-group acl-number rule
rule-id
Apply one rule in a user-defined ACL
separately
user-group acl-number
Apply all rules in a user-defined ACL
separately
user-group acl-number rule
rule-id
Apply one rule in an IP type ACL and one rule
in a Layer 2 ACL simultaneously
ip-group acl-number rule rule-id
link-group acl-number rule
rule-id
