Huawei Quidway S6500 Series Command Manual

Command Manual - Network Protocol
Quidway S6500 Series Ethernet Switches Chapter 2 ARP Configuration Commands
Huawei Technologies Proprietary
2-4
, sender_eth_addr : 0019-9612-0601,sender_ip_addr : 10.0.0.2,
target_eth_addr :
0000-0000-0000, target_ip_addr : 10.153t d
*Aug 31 10:30:20 2005 C_0.6506r ARP/8/arp_rcv:Receive an ARP Packet,
operation :
2, sender_eth_addr : 000f-1f9b-8b98, sender_ip_addr : 10.153.81.10,
target_eth_
addr : 0019-9612-0601, target_ip_addr : 10.0.0.2
*Aug 31 10:30:21 2005 C_0.6506r ARP/8/arp_send:Send an ARP Packet, operation :
1
, sender_eth_addr : 0019-9612-0601,sender_ip_addr : 193.1.1.2,
target_eth_addr :
0000-0000-0000, target_ip_addr : 193.1.1.4
*Aug 31 10:30:21 2005 C_0.6506r ARP/8/arp_rcv:Receive an ARP Packet,
operation :
2, sender_eth_addr : 000f-e200-8001, sender_ip_addr : 193.1.1.4,
target_eth_add
r : 0019-9612-0601, target_ip_addr : 193.1.1.2
Table 2-1 Output description of the debugging arp packet display
Field Description
operation
Kind of ARP packets: 1 ARP request packet; 2 ARP reply
packet
sender_eth_addr Ethernet address of the sender
sender_ip_addr IP address of the sender
target_eth_addr
Target Ethernet address. If the packet is ARP request packet,
the target IP address will be 0
target_ip_addr Target IP address
2.1.5 display arp
Syntax
display arp [ ip-address | [ dynamic | static ]
View
Any view
Parameter
dynamic: Display the dynamic ARP entries in ARP mapping table.
