Command Manual - QoS/ACL
Quidway S6500 Series Ethernet Switches Chapter 2 Qos Command
Huawei Technologies Proprietary
2-19
 Note:
Restrictions of port mirroring configuration:
z The mirroring port and the mirrored port must be located at the same interface card.
z As for a non-48-port interface card, only one port mirroring group can be configured
in one mirroring direction. For instance, one interface card can be configured with
only one port mirroring group for monitoring received packets. If you configure
another port mirroring group for monitoring received packets, the system will prompt
that configuration fails. The restrictions of port mirroring configuration for monitoring
sent packets is similar to this one.
z As for a 48-port interface card, the monitoring port and the monitored port must
belong to the same port range simultaneously, that is, either 1-24 ports or 25-48
ports. Only one port mirroring group can be configured in one mirroring direction For
instance, in the range of port 1 to port 24, one interface card can be configured with
only one port mirroring group for monitoring received packets. If you configure
another port mirroring group for monitoring received packets, the system will prompt
that configuration fails. The restrictions of port mirroring configuration for monitoring
sent packets is similar to this one.
For the related configuration, see display mirroring-group.
Example
#Configure mirroring group 1; the monitored port is Ethernet3/0/1~Ethernet3/0/3; the
monitoring port is Ethernet3/0/4; only packets received by port are monitored.
[Quidway] mirroring-group 1 inbound ethernet 3/0/1 to ethernet 3/0/3 mirrored-to
ethernet 3/0/4
2.1.16 priority
Syntax
priority priority-level
undo priority
View
Ethernet port view
Parameter
priority-level: The value of port priority level, ranging from 0 to 7.
