:WGEN Commands 33
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 1009
Query Syntax :WGEN:FUNCtion?
The :WGEN:FUNCtion? query returns the currently selected signal type.
Return Format
<signal><NL>
<signal> ::= {SIN | SQU | RAMP | PULS | DC | NOIS | SINC | EXPR | EXPF
| CARD | GAUS | ARB}
See Also • "Introduction to :WGEN Commands" on page 998
• ":WGEN:MODulation:NOISe" on page 1021
CARDiac Use these commands to set the cardiac signal
parameters:
• ":WGEN:FREQuency" on page 1006
• ":WGEN:PERiod" on page 1027
• ":WGEN:VOLTage" on page 1029
• ":WGEN:VOLTage:OFFSet" on page 1032
100 mHz to
200 kHz
20 mVpp to
5Vpp
±1.25 V
GAUSsian Use these commands to set the gaussian pulse
signal parameters:
• ":WGEN:FREQuency" on page 1006
• ":WGEN:PERiod" on page 1027
• ":WGEN:VOLTage" on page 1029
• ":WGEN:VOLTage:OFFSet" on page 1032
100 mHz to
5MHz
20 mVpp to
4Vpp
±1.25 V
ARBitrary Use these commands to set the arbitrary signal
parameters:
• ":WGEN:FREQuency" on page 1006
• ":WGEN:PERiod" on page 1027
• ":WGEN:VOLTage" on page 1029
• ":WGEN:VOLTage:OFFSet" on page 1032
• ":WGEN:VOLTage:HIGH" on page 1030
• ":WGEN:VOLTage:LOW" on page 1031
100 mHz to
12 MHz
20 mVpp to
5Vpp
±2.50 V
1
When the output load is 50 Ω, these values are halved.
Waveform
Type
Characteristics Frequency
Range
Max.
Amplitude
(High-Z)
1
Offset
(High-Z)
1
