118 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SBUS<n>:A429:TRIGger
:LABel <value> (see
page 645)
:SBUS<n>:A429:TRIGger
:LABel? (see
page 645)
<value> ::= 8-bit integer in
decimal, <hex>, <octal>, or
<string> from 0-255 or "0xXX"
(don't care)
<hex> ::= #Hnn where n ::=
{0,..,9 | A,..,F}
<octal> ::= #Qnnn where n ::=
{0,..,7}
<string> ::= "0xnn" where n::=
{0,..,9 | A,..,F}
:SBUS<n>:A429:TRIGger
:PATTern:DATA
<string> (see
page 646)
:SBUS<n>:A429:TRIGger
:PATTern:DATA? (see
page 646)
<string> ::= "nn...n" where n ::=
{0 | 1 | X}, length depends on
FORMat
:SBUS<n>:A429:TRIGger
:PATTern:SDI <string>
(see page 647)
:SBUS<n>:A429:TRIGger
:PATTern:SDI? (see
page 647)
<string> ::= "nn" where n ::= {0
| 1 | X}, length always 2 bits
:SBUS<n>:A429:TRIGger
:PATTern:SSM <string>
(see page 648)
:SBUS<n>:A429:TRIGger
:PATTern:SSM? (see
page 648)
<string> ::= "nn" where n ::= {0
| 1 | X}, length always 2 bits
:SBUS<n>:A429:TRIGger
:RANGe <min>,<max>
(see page 649)
:SBUS<n>:A429:TRIGger
:RANGe? (see
page 649)
<min> ::= 8-bit integer in
decimal, <hex>, <octal>, or
<string> from 0-255
<max> ::= 8-bit integer in
decimal, <hex>, <octal>, or
<string> from 0-255
<hex> ::= #Hnn where n ::=
{0,..,9 | A,..,F}
<octal> ::= #Qnnn where n ::=
{0,..,7}
<string> ::= "0xnn" where n::=
{0,..,9 | A,..,F}
:SBUS<n>:A429:TRIGger
:TYPE <condition>
(see page 650)
:SBUS<n>:A429:TRIGger
:TYPE? (see page 650)
<condition> ::= {WSTArt | WSTOp |
LABel | LBITs | PERRor | WERRor |
GERRor | WGERrors | ALLerrors |
LRANge | ABITs | AOBits | AZBits}
Table 24 :SBUS<n>:A429 Commands Summary (continued)
Command Query Options and Query Returns
