4 Commands Quick Reference
:SBUS<n>:CAN:TRIGger:
PATTern:ID <string>
(see page 667)
:SBUS<n>:CAN:TRIGger:
PATTern:ID? (see
page 667)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:CAN:TRIGger:
PATTern:ID:MODE
<value> (see
page 668)
:SBUS<n>:CAN:TRIGger:
PATTern:ID:MODE? (see
page 668)
<value> ::= {STANdard | EXTended}
Table 25 :SBUS<n>:CAN Commands Summary (continued)
Command Query Options and Query Returns
Table 26 :SBUS<n>:FLEXray Commands Summary
Command Query Options and Query Returns
:SBUS<n>:FLEXray:AUTo
setup (see page 671)
n/a n/a
:SBUS<n>:FLEXray:BAUD
rate <baudrate> (see
page 672)
:SBUS<n>:FLEXray:BAUD
rate? (see page 672)
<baudrate> ::= {2500000 | 5000000
| 10000000}
:SBUS<n>:FLEXray:CHAN
nel <channel> (see
page 673)
:SBUS<n>:FLEXray:CHAN
nel? (see page 673)
<channel> ::= {A | B}
n/a :SBUS<n>:FLEXray:COUN
t:NULL? (see
page 674)
<frame_count> ::= integer in NR1
format
:SBUS<n>:FLEXray:COUN
t:RESet (see
page 675)
n/a n/a
n/a :SBUS<n>:FLEXray:COUN
t:SYNC? (see
page 676)
<frame_count> ::= integer in NR1
format
n/a :SBUS<n>:FLEXray:COUN
t:TOTal? (see
page 677)
<frame_count> ::= integer in NR1
format
:SBUS<n>:FLEXray:SOUR
ce <source> (see
page 678)
:SBUS<n>:FLEXray:SOUR
ce? (see page 678)
<source> ::= {CHANnel<n>}
<n> ::= 1-2 or 1-4 in NR1 format
:SBUS<n>:FLEXray:TRIG
ger <condition> (see
page 679)
:SBUS<n>:FLEXray:TRIG
ger? (see page 679)
<condition> ::= {FRAMe | ERRor |
EVENt}
