198 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide

6 Root (:) Commands

:BLANk

(see page 1138)

Command Syntax

:BLANk [<source>]

<source> ::= {CHANnel<n> | FUNCtion | MATH | SBUS{1 | 2} | WMEMory<r>}

for the DSO models

<source> ::= {CHANnel<n> | DIGital<d> | POD{1 | 2}

| BUS{1 | 2} | FUNCtion | MATH | SBUS{1 | 2} | WMEMory<r>}

for the MSO models

<n> ::= 1 to (# analog channels) in NR1 format

<d> ::= 0 to (# digital channels - 1) in NR1 format

<r> ::= 1 to (# ref waveforms) in NR1 format

The :BLANk command turns off (stops displaying) the specified channel,

digital pod, math function, or serial decode bus. The :BLANk command

with no parameter turns off all sources.

See Also • "Introduction to Root (:) Commands" on page 190

• ":DISPlay:CLEar" on page 303

• ":CHANnel<n>:DISPlay" on page 266

• ":DIGital<d>:DISPlay" on page 291

• ":FUNCtion:DISPlay" on page 333

• ":POD<n>:DISPlay" on page 525

• ":WMEMory<r>:DISPlay" on page 1036

• ":STATus" on page 222

• ":VIEW" on page 225

Example Code • "Example Code" on page 225

NOTE

To turn on (start displaying) a channel, etc., use the :VIEW command. The DISPlay

commands, :CHANnel<n>:DISPlay, :FUNCtion:DISPlay, :POD<n>:DISPlay,

:DIGital<n>:DISPlay, :SBUS<n>:DISPlay, or :WMEMory<r>:DISPlay, are the preferred

method to turn on/off a channel, etc.

NOTE

MATH is an alias for FUNCtion.
