Root (:) Commands 6

Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 199

:DIGitize

(see page 1138)

Command Syntax

:DIGitize [<source>[,..,<source>]]

<source> ::= {CHANnel<n> | FUNCtion | MATH | SBUS{1 | 2}}

for the DSO models

<source> ::= {CHANnel<n> | DIGital<d> | POD{1 | 2}

| BUS{1 | 2} | FUNCtion | MATH | SBUS{1 | 2}}

for the MSO models

<n> ::= 1 to (# analog channels) in NR1 format

<d> ::= 0 to (# digital channels - 1) in NR1 format

The <source> parameter may be repeated up to 5 times.

The :DIGitize command is a specialized RUN command. It causes the

instrument to acquire waveforms according to the settings of the :ACQuire

commands subsystem. When the acquisition is complete, the instrument is

stopped.

If no argument is given, :DIGitize acquires the channels currently

displayed. If no channels are displayed, all channels are acquired.

See Also • "Introduction to Root (:) Commands" on page 190

• ":RUN" on page 219

• ":SINGle" on page 221

• ":STOP" on page 223

• ":TIMebase:MODE" on page 867

• Chapter 7, “:ACQuire Commands,” starting on page 227

• Chapter 32, “:WAVeform Commands,” starting on page 959

NOTE

The :DIGitize command is only executed when the :TIMebase:MODE is MAIN or WINDow.

NOTE

To halt a :DIGitize in progress, use the device clear command.

NOTE

MATH is an alias for FUNCtion.
