Agilent InfiniiVision 3000 X-Series Oscilloscopes
Programmer's Guide
15
:EXTernal Trigger Commands
Control the input characteristics of the external trigger input. See
"Introduction to :EXTernal Trigger Commands" on page 317.
Introduction to
:EXTernal Trigger
Commands
The EXTernal trigger subsystem commands control the input
characteristics of the external trigger input. The probe factor, impedance,
input range, input protection state, units, and bandwidth limit settings
may all be queried. Depending on the instrument type, some settings may
be changeable.
Reporting the Setup
Use :EXTernal? to query setup information for the EXTernal subsystem.
Return Format
The following is a sample response from the :EXTernal query. In this case,
the query was issued following a *RST command.
:EXT:BWL 0;RANG +8E+00;UNIT VOLT;PROB +1.000E+00
Table 87 :EXTernal Trigger Commands Summary
Command Query Options and Query Returns
:EXTernal:BWLimit
<bwlimit> (see
page 318)
:EXTernal:BWLimit?
(see page 318)
<bwlimit> ::= {0 | OFF}
:EXTernal:PROBe
<attenuation> (see
page 319)
:EXTernal:PROBe? (see
page 319)
<attenuation> ::= probe
attenuation ratio in NR3 format
:EXTernal:RANGe
<range>[<suffix>]
(see page 320)
:EXTernal:RANGe? (see
page 320)
<range> ::= vertical full-scale
range value in NR3 format
<suffix> ::= {V | mV}
:EXTernal:UNITs
<units> (see
page 321)
:EXTernal:UNITs? (see
page 321)
<units> ::= {VOLT | AMPere}
