What's New 1
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 39
:SEARch:SERial:FLEXray Commands (see
page 814)
Commands for finding FlexRay events in the
captured data.
:SEARch:SERial:M1553 Commands (see
page 839)
Commands for finding MIL-STD 1553 events in
the captured data.
:TRIGger:TV:UDTV:ENUMber (see page 949) Specifies the Nth edge to trigger on with the
Generic video trigger. Available with the
DSOX3VID extended Video triggering license.
:TRIGger:TV:UDTV:HSYNc (see page 950) Enables or disables the horizontal sync control
in the Generic video trigger. Available with the
DSOX3VID extended Video triggering license.
:TRIGger:TV:UDTV:HTIMe (see page 951) When the Generic video trigger's horizontal
sync control is enabled, this command
specifies the sync time. Available with the
DSOX3VID extended Video triggering license.
:TRIGger:TV:UDTV:PGTHan (see page 952) Specifies the "greater than the sync pulse
width" time in the Generic video trigger.
Available with the DSOX3VID extended Video
triggering license.
:WGEN:ARBitrary:BYTeorder (see page 999) Selects the byte order for arbitrary waveform
binary transfers.
:WGEN:ARBitrary:DATA (see page 1000) Downloads an arbitrary waveform in
floating-point values format.
:WGEN:ARBitrary:DATA:ATTRibute:POINts?
(see page 1001)
Returns the number of points used by the
current arbitrary waveform.
:WGEN:ARBitrary:DATA:CLEar (see page 1002) Clears the arbitrary waveform memory and
restores the default waveform.
:WGEN:ARBitrary:DATA:DAC (see page 1003) Downloads an arbitrary waveform in integer
(DAC) values.
:WGEN:ARBitrary:INTerpolate (see page 1004) Enable or disables interpolated values between
points in the arbitrary waveform.
:WGEN:ARBitrary:STORe (see page 1005) Captures a waveform and stores it into
arbitrary waveform memory.
:WGEN:MODulation:NOISe (see page 1021) Adds noise to the waveform generator's output
signal.
Command Description
