Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

400 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
20 :MEASure Commands
:MEASure:PERiod
[<source>] (see
page 433)
:MEASure:PERiod?
[<source>] (see
page 433)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>} for
DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | FUNCtion | MATH |
WMEMory<r>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= waveform
period in seconds in NR3 format
:MEASure:PHASe
[<source1>]
[,<source2>] (see
page 434)
:MEASure:PHASe?
[<source1>]
[,<source2>] (see
page 434)
<source1,2> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= the phase
angle value in degrees in NR3
format
:MEASure:PPULses
[<source>] (see
page 435)
:MEASure:PPULses?
[<source>] (see
page 435)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= the rising
pulse count in NR3 format
:MEASure:PREShoot
[<source>] (see
page 436)
:MEASure:PREShoot?
[<source>] (see
page 436)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= the percent of
preshoot of the selected waveform
in NR3 format
Table 92 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
