48 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide

1 What's New

Obsolete

Commands

Discontinued

Commands

:WAVeform:SOURce (see

page 981)

Can select reference waveforms as the source.

:VIEW (see page 225) PMEMory (pixel memory) locations are not present.

Command Differences From InfiniiVision 7000B Series Oscilloscopes

Obsolete Command Current Command Equivalent Behavior Differences

Command Description

:ACQuire:RSIGnal The 3000 X-Series oscilloscope does not have a 10 MHz REF

BNC connector.

:CALibrate:SWITch? Replaced by :CALibrate:PROTected? (see page 256). The

oscilloscope has a protection button instead of a switch.

:DISPlay:SOURce PMEMory (pixel memory) locations are not present.

:EXTernal:IMPedance External TRIG IN connector is now fixed at 1 MOhm.

:EXTernal:PROBe:ID Not supported on external TRIG IN connector.

:EXTernal:PROBe:STYPe Not supported on external TRIG IN connector.

:EXTernal:PROTection Not supported on external TRIG IN connector.

:HARDcopy:DEVice,

:HARDcopy:FORMat

Use the :SAVE:IMAGe:FORMat, :SAVE:WAVeform:FORMat, and

:HARDcopy:APRinter commands instead.

:MERGe Waveform traces have been replaced by reference waveforms.

:RECall:IMAGe[:STARt] Waveform traces have been replaced by reference waveforms.

:SYSTem:PRECision The 3000 X-Series oscilloscopes' measurement record is 62,500

points, and there is no need for a special precision mode.

:TIMebase:REFClock The 3000 X-Series oscilloscope does not have a 10 MHz REF

BNC connector.
