What's New 1
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 47
Changed
Commands
:TRIGger:RUNT Commands
(see page 927)
Commands for triggering on runt pulses.
:TRIGger:SHOLd Commands
(see page 932)
Commands for triggering on setup and hold time violations.
:TRIGger:TRANsition
Commands (see page 938)
Commands for triggering on edge transitions.
:WGEN Commands (see
page 995)
Commands for controlling the built-in waveform generator (with
Option WGN license).
:WMEMory<r> Commands
(see page 1033)
Commands for reference waveforms.
Command Description
Command Differences From InfiniiVision 7000B Series Oscilloscopes
:ACQuire:MODE (see
page 231)
There is no ETIMe parameter with the 3000 X-Series
oscilloscopes.
:CALibrate:OUTPut (see
page 255)
The TRIG OUT signal can be a trigger output, mask test failure,
or waveform generator sync pulse.
:DISPlay:DATA (see page 304) Monochrome TIFF images of the graticule cannot be saved or
restored.
:DISPlay:LABList (see
page 306)
The label list contains up to 77, 10-character labels (instead of
75).
:DISPlay:VECTors (see
page 308)
Always ON with 3000 X-Series oscilloscopes.
:MARKer Commands (see
page 379)
Can select reference waveforms as marker source.
:MEASure Commands (see
page 395)
Can select reference waveforms as the source for many
measurements.
General :SBUS<n>
Commands (see page 631)
With multiple serial decode waveforms, "SBUS" is now
"SBUS1" or "SBUS2".
:SAVE:IMAGe[:STARt] (see
page 610)
Cannot save images to internal locations.
:SEARch:MODE (see
page 780)
Can select EDGE, GLITch, RUNT, and TRANsition modes. Also,
SERial is now SERial{1 | 2}.
:SEARch:SERial:IIC:MODE
(see page 827)
ANACknowledge parameter is now ANACk.
:TRIGger:PATTern (see
page 919)
Takes <string> parameter instead of <value>,<mask>
parameters.
