Agilent InfiniiVision 3000 X-Series Oscilloscopes
Programmer's Guide
25
:RECall Commands
Recall previously saved oscilloscope setups, reference waveforms, and
masks.
Table 97 :RECall Commands Summary
Command Query Options and Query Returns
:RECall:ARBitrary:[ST
ARt] [<file_spec>][,
<column>] (see
page 599)
n/a <file_spec> ::= {<internal_loc>
| <file_name>}
<column> ::= Column in CSV file
to load. Column number starts
from 1.
<internal_loc> ::= 0-3; an
integer in NR1 format
<file_name> ::= quoted ASCII
string
:RECall:FILename
<base_name> (see
page 600)
:RECall:FILename?
(see page 600)
<base_name> ::= quoted ASCII
string
:RECall:MASK[:STARt]
[<file_spec>] (see
page 601)
n/a <file_spec> ::= {<internal_loc>
| <file_name>}
<internal_loc> ::= 0-3; an
integer in NR1 format
<file_name> ::= quoted ASCII
string
:RECall:PWD
<path_name> (see
page 602)
:RECall:PWD? (see
page 602)
<path_name> ::= quoted ASCII
string
