Agilent InfiniiVision 3000 X-Series Oscilloscopes
Programmer's Guide
27
:SBUS<n> Commands
Control the modes and parameters for each serial bus decode/trigger type.
See:
• "Introduction to :SBUS<n> Commands" on page 629
• "General :SBUS<n> Commands" on page 631
• ":SBUS<n>:A429 Commands" on page 634
• ":SBUS<n>:CAN Commands" on page 652
• ":SBUS<n>:FLEXray Commands" on page 669
• ":SBUS<n>:I2S Commands" on page 688
• ":SBUS<n>:IIC Commands" on page 707
• ":SBUS<n>:LIN Commands" on page 717
• ":SBUS<n>:M1553 Commands" on page 731
• ":SBUS<n>:SPI Commands" on page 738
• ":SBUS<n>:UART Commands" on page 754
Introduction to
:SBUS<n>
Commands
The :SBUS subsystem commands control the serial decode bus viewing,
mode, and other options.
The following serial bus decode/trigger types are available (see
":TRIGger:MODE" on page 886).
• CAN (Controller Area Network) triggering— will trigger on CAN
version 2.0A and 2.0B signals. Setup consists of connecting the
oscilloscope to a CAN signal. Baud rate, signal source, and signal
polarity, and type of data to trigger on can be specified. You can trigger
on CAN data and identifier patterns and you can set the bit sample
point.
• I2S (Inter- IC Sound or Integrated Interchip Sound bus) triggering—
consists of connecting the oscilloscope to the serial clock, word select,
and serial data lines, then triggering on a data value.
NOTE
These commands are only valid on oscilloscope models when a serial decode option has
been licensed.
