Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

:SBUS<n> Commands 27
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 739
:SBUS<n>:SPI:SOURce:M
OSI <source> (see
page 747)
:SBUS<n>:SPI:SOURce:M
OSI? (see page 747)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:DATA
<string> (see
page 748)
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:DATA?
(see page 748)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:WIDTh
<width> (see
page 749)
:SBUS<n>:SPI:TRIGger:
PATTern:MISO:WIDTh?
(see page 749)
<width> ::= integer from 4 to 64
in NR1 format
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:DATA
<string> (see
page 750)
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:DATA?
(see page 750)
<string> ::= "nn...n" where n ::=
{0 | 1 | X | $}
<string ::= "0xnn...n" where n
::= {0,..,9 | A,..,F | X | $}
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:WIDTh
<width> (see
page 751)
:SBUS<n>:SPI:TRIGger:
PATTern:MOSI:WIDTh?
(see page 751)
<width> ::= integer from 4 to 64
in NR1 format
:SBUS<n>:SPI:TRIGger:
TYPE <value> (see
page 752)
:SBUS<n>:SPI:TRIGger:
TYPE? (see page 752)
<value> ::= {MOSI | MISO}
:SBUS<n>:SPI:WIDTh
<word_width> (see
page 753)
:SBUS<n>:SPI:WIDTh?
(see page 753)
<word_width> ::= integer 4-16 in
NR1 format
Table 107 :SBUS<n>:SPI Commands Summary (continued)
Command Query Options and Query Returns
