Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

:SBUS<n> Commands 27
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 755
:SBUS<n>:UART:SOURce:
RX <source> (see
page 767)
:SBUS<n>:UART:SOURce:
RX? (see page 767)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:UART:SOURce:
TX <source> (see
page 768)
:SBUS<n>:UART:SOURce:
TX? (see page 768)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:UART:TRIGger
:BASE <base> (see
page 769)
:SBUS<n>:UART:TRIGger
:BASE? (see page 769)
<base> ::= {ASCii | HEX}
:SBUS<n>:UART:TRIGger
:BURSt <value> (see
page 770)
:SBUS<n>:UART:TRIGger
:BURSt? (see
page 770)
<value> ::= {OFF | 1 to 4096 in
NR1 format}
:SBUS<n>:UART:TRIGger
:DATA <value> (see
page 771)
:SBUS<n>:UART:TRIGger
:DATA? (see page 771)
<value> ::= 8-bit integer from
0-255 (0x00-0xff) in decimal,
<hexadecimal>, <binary>, or
<quoted_string> format
<hexadecimal> ::= #Hnn where n
::= {0,..,9 | A,..,F} for
hexadecimal
<binary> ::= #Bnn...n where n ::=
{0 | 1} for binary
<quoted_string> ::= any of the
128 valid 7-bit ASCII characters
(or standard abbreviations)
:SBUS<n>:UART:TRIGger
:IDLE <time_value>
(see page 772)
:SBUS<n>:UART:TRIGger
:IDLE? (see page 772)
<time_value> ::= time from 1 us
to 10 s in NR3 format
:SBUS<n>:UART:TRIGger
:QUALifier <value>
(see page 773)
:SBUS<n>:UART:TRIGger
:QUALifier? (see
page 773)
<value> ::= {EQUal | NOTequal |
GREaterthan | LESSthan}
Table 108 :SBUS<n>:UART Commands Summary (continued)
Command Query Options and Query Returns
