Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 97
:MEASure:DUAL:VAMPlit
ude
[<source1>][,<source2
>] (see page 419)
:MEASure:DUAL:VAMPlit
ude?
[<source1>][,<source2
>] (see page 419)
<source1>,<source2> ::=
CHANnel<n> with N2820A probe
connected
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= the amplitude
of the selected waveform in volts
in NR3 format
:MEASure:DUAL:VAVerag
e [<interval>]
[,<source1>][,<source
2>] (see page 420)
:MEASure:DUAL:VAVerag
e? [<interval>]
[,<source1>][,<source
2>] (see page 420)
<interval> ::= {CYCLe | DISPlay}
<source1>,<source2> ::=
CHANnel<n> with N2820A probe
connected
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= calculated
average voltage in NR3 format
:MEASure:DUAL:VBASe
[<source1>][,<source2
>] (see page 421)
:MEASure:DUAL:VBASe?
[<source1>][,<source2
>] (see page 421)
<source1>,<source2> ::=
CHANnel<n> with N2820A probe
connected
<n> ::= 1 to (# analog channels)
in NR1 format
<base_voltage> ::= voltage at the
base of the selected waveform in
NR3 format
:MEASure:DUAL:VPP
[<source1>][,<source2
>] (see page 422)
:MEASure:DUAL:VPP?
[<source1>][,<source2
>] (see page 422)
<source1>,<source2> ::=
CHANnel<n> with N2820A probe
connected
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= voltage
peak-to-peak of the selected
waveform in NR3 format
:MEASure:DUAL:VRMS
[<interval>]
[,<type>]
[,<source1>][,<source
2>] (see page 423)
:MEASure:DUAL:VRMS?
[<interval>]
[,<type>]
[,<source1>][,<source
2>] (see page 423)
<interval> ::= {CYCLe | DISPlay}
<type> ::= {AC | DC}
<source1>,<source2> ::=
CHANnel<n> with N2820A probe
connected
<n> ::= 1 to (# analog channels)
in NR1 format
<return_value> ::= calculated
RMS voltage in NR3 format
Table 17 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
