Agilent Technologies InfiniiVision 3000 X-Series - Page 99

Commands Quick Reference 4
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 99
:MEASure:NEDGes
[<source>] (see
page 427)
:MEASure:NEDGes?
[<source>] (see
page 427)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= the falling
edge count in NR3 format
:MEASure:NPULses
[<source>] (see
page 428)
:MEASure:NPULses?
[<source>] (see
page 428)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= the falling
pulse count in NR3 format
:MEASure:NWIDth
[<source>] (see
page 429)
:MEASure:NWIDth?
[<source>] (see
page 429)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>} for
DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | FUNCtion | MATH |
WMEMory<r>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<return_value> ::= negative
pulse width in seconds-NR3 format
:MEASure:OVERshoot
[<source>] (see
page 430)
:MEASure:OVERshoot?
[<source>] (see
page 430)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= the percent of
the overshoot of the selected
waveform in NR3 format
:MEASure:PEDGes
[<source>] (see
page 432)
:MEASure:PEDGes?
[<source>] (see
page 432)
<source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1-2 in NR1 format
<return_value> ::= the rising
edge count in NR3 format
Table 17 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
