System Control Coprocessor

ID012310 Non-Confidential, Unrestricted Access

cache to contain valid or dirty Non-secure entries when the Non-secure clean or clean and

invalidate all operation completes. To avoid this kind of problem, the Secure side must not

allocate Non-secure entries into the cache and must treat all writes to Non-secure regions that

hit in the cache as write-though.

Note

Three bits, nWT, nIL and nDL, are also defined for Debug state in CP14, see CP14 c10, Debug

State Cache Control Register on page 13-23, and apply to all Secure and Non-secure regions.

The CP14 register has precedence over the CP15 register when the core is in Debug state, and

the CP15 register has precedence over the CP14 register in functional states.

For more information on cache debug, see Chapter 13 Debug.
