Coprocessor Interface

ID012310 Non-Confidential, Unrestricted Access

11.2 Coprocessor pipeline

The coprocessor interface achieves loose synchronization between the two pipelines by

exchanging tokens from one pipeline to the other. These tokens pass down queues between the

pipelines and can carry additional information. In most cases the primary purpose of the queue

is to carry information about the instruction being processed, or to inform one pipeline of events

occurring in the other.

Tokens are generated whenever a coprocessor instruction passes out of a pipeline stage

associated with a queue into the next stage. These tokens are picked up by the partner stage in

the other pipeline, and used to enable the corresponding instruction in that stage to move on. The

movement of coprocessor instructions down each pipeline is matched exactly by the movement

of tokens along the various queues that connect the pipelines.

If a pipeline stage has no associated queue, the instruction contained within it moves on in the

normal way. The coprocessor interface is data-driven rather than control-driven.

11.2.1 Coprocessor instructions

Each coprocessor might only execute a subset of all possible coprocessor instructions.

Coprocessors reject those instructions they cannot handle. Table 11-1 lists all the coprocessor

instructions supported by the processor and gives a brief description of each. For more details

of coprocessor instructions, see the ARM Architecture Reference Manual.

The coprocessor instructions fall into three groups:

• loads

•stores

• processing instructions.

The load and store instructions enable information to pass between the core and the coprocessor.

Some of them might be vectored. This enables several values to be transferred in a single

instruction. This typically involves the transfer of several words of data between a set of registers

in the coprocessor and a contiguous set of locations in memory.

Table 11-1 Coprocessor instructions

Instruction Data transfer Vectored Description

CDP None No Processes information already held within the coprocessor

MRC Store No Transfers information from the coprocessor to the core registers

MCR Load No Transfers information from the core registers to the coprocessor

MRRC Store No Transfers information from the coprocessor to a pair of registers in the

core

MCRR Load No Transfers information from a pair of registers in the core to the

coprocessor

STC Store Yes Transfers information from the coprocessor to memory and might be

iterated to transfer a vector

LDC Load Yes Transfers information from memory to the coprocessor and might be

iterated to transfer a vector
