Signal Descriptions

ID012310 Non-Confidential, Unrestricted Access

A.3 TrustZone internal signals

Table A-3 lists the processor TrustZone internal signals. Depending on the implementation,

these signals do not appear at the chip level.

Table A-3 TrustZone internal signals

Name Direction Description

CP15SDISABLE Input Disables write access to some system control processor registers

SECMONBUS[24:0] Output Monitors the state of some of the key signals in the processor
