8.5.13 Noncacheable LDM10
A Noncacheable LDM10 is split into two or three operations as shown in Table 8-36.
8.5.14 Noncacheable LDM11
A Noncacheable LDM11 is split into two or three operations as shown in Table 8-37.
0x14 , word 5 LDM3 from 0x14 + LDM6 from 0x00
0x18
, word 6 LDM2 from 0x18 + LDM7 from 0x00
0x1C
, word 7 LDR from 0x1C + LDM8 from 0x00
Table 8-35 Noncacheable LDM9 (continued)
Address[4:0] Operations
Table 8-36 Noncacheable LDM10
Address[4:0] Operations
0x00 , word 0 LDM8 from 0x00 + LDM2 from 0x00
0x04
, word 1 LDM7 from 0x04 + LDM3 from 0x00
0x08
, word 2 LDM6 from 0x08 + LDM4 from 0x00
0x0C
, word 3 LDM5 from 0x0C + LDM5 from 0x00
0x10
, word 4 LDM4 from 0x10 + LDM6 from 0x00
0x14
, word 5 LDM3 from 0x14 + LDM7 from 0x00
0x18
, word 6 LDM2 from 0x18 + LDM8 from 0x00
0x1C
, word 7 LDR from 0x1C + LDM8 from 0x00 + LDR from 0x00
Table 8-37 Noncacheable LDM11
Address[4:0] Operations
0x00 , word 0 LDM8 from 0x00 + LDM3 from 0x00
0x04
, word 1 LDM7 from 0x04 + LDM4 from 0x00
0x08
, word 2 LDM6 from 0x08 + LDM5 from 0x00
0x0C
, word 3 LDM5 from 0x0C + LDM6 from 0x00
0x10
, word 4 LDM4 from 0x10 + LDM7 from 0x00
0x14
, word 5 LDM3 from 0x14 + LDM8 from 0x00
0x18
, word 6 LDM2 from 0x18 + LDM8 from 0x00 + LDR from 0x00
0x1C
, word 7 LDR from 0x1C + LDM8 from 0x00 + LDM2 from 0x00
