Cycle Timings and Interlock Behavior

ID012310 Non-Confidential, Unrestricted Access

16.9 Processor state updating instructions

This section describes the cycle timing behavior for the MSR, MRS, CPS, and SETEND

instructions. Table 16-12 lists processor state updating instructions and their cycle timing

behavior.

Table 16-12 Processor state updating instructions cycle timing behavior

instruction Cycles Comments

MRS

1 All MRS instructions

MSR CPSR_f, s, fs

2 MSRs to CPSR flags and or status

MSR

4 All other MSRs to the CPSR

MSR SPSR

5 All MSRs to the SPSR

CPS <effect> <iflags>

1 Interrupt masks only

CPS <effect> <iflags>, #<mode>

2 Mode changing

SETEND
