A.2 Static configuration signals

Table A-2 lists the processor static configuration signals.

Table A-2 Static configuration signals

Name Direction Description

BIGENDINIT Input When HIGH indicates v5 Big-endian mode.

CFGBIGEND Output Current state of CP15 Bigend bit.

INITRAM Input Determines the reset value of the En bit, bit 0, of the Instruction TCM Region Register.

When HIGH this bit resets to 1 and the Instruction TCM is enabled on reset. For more

information see c9, Instruction TCM Region Register on page 3-91.

UBITINIT Input When HIGH indicates ARMv6 unaligned behavior.

VINITHI Input When HIGH indicates High Vecs mode.
